45# Steel Round Downspout Roll Forming Machine With Electric Control System

Çin 45# Steel Round Downspout Roll Forming Machine With Electric Control System Tedarikçi
45# Steel Round Downspout Roll Forming Machine With Electric Control System Tedarikçi 45# Steel Round Downspout Roll Forming Machine With Electric Control System Tedarikçi 45# Steel Round Downspout Roll Forming Machine With Electric Control System Tedarikçi 45# Steel Round Downspout Roll Forming Machine With Electric Control System Tedarikçi

Büyük resim :  45# Steel Round Downspout Roll Forming Machine With Electric Control System

Ürün ayrıntıları:

Place of Origin: Botou Hebei China
Marka adı: HC
Sertifika: ISO
Model Number: HC100

Ödeme & teslimat koşulları:

Minimum Order Quantity: 1set
Fiyat: 25000-49000USD
Packaging Details: Main machine is nude,the computer control box is packed by carton box
Delivery Time: 30days
Payment Terms: 30% deposit by T/T in advance and 70% balance after inspection confirmation before shipment
Supply Ability: 20 sets/month
Contact Now
Detaylı ürün tanımı

45# Steel Round Downspout Roll Forming Machine With Electric Control System





Quick Detail:



1. Suitable to process: Color steel plate

2. Width of the plate: 330mm

3. Rollers: 15 rows

4. Dimensions: 7.4*1.15*1.51m

5. Power: 5.5+4kw

6. Rolling material: high grade 45# steel(plated chrome on surface)

7. Thickness of the plate:0.3-0.6 mm

8. Voltage: 380V 50Hz 3phases

9. Material of the cutting plate: Cr12

10. Hydraulic: 40#

11. Processing precision: Within 1.00mm

12. Control system: PLC control





Description:



Downspout Roll Forming Machine  Main parameter

No.

   Main parameter of Downspout Roll Forming Machine

1

Suitable to process

Color steel plate

2

Width of the plate

330mm

3

Rollers

15rows

4

Dimensions

7400*1150*1510mm

5

Power

5.5+4kw

6

Rolling material

high grade 45# steel(plated chrome on surface)

6

Thickness of the plate

0.3-0.6mm

7

Productivity

8-10m/min

8

Diameter of the roller

Φ66mm

9

Voltage

380V 50Hz 3phases

10

Material of the cutting plate

Cr12

11

Hydraulic

40#

12

Processing precision

Within 1.00mm

13

Control system

PLC control

Equipment components: Man-made uncoiler-roll forming machine-computer control system-hydraulic control system-cutting





Application



The roll formed product is mor durable than the tranditional ppc pipe, and not easy to aging.

It will make the project more integrate, and help enhancing the image of all project.

Drainpipe bending machine used for bend the roll formed pipe, to connect the drainpipe and the elbowed pipe.





Competitive Advantage





1. CE certification

2 .ISO certification

3. working life 20 years

4. high quality steel

5. High efficiency
