Building Material Steel Wall Panel Roll Forming Machine Hydraulic

Müşteri yorumları
Makine kullanımı kolay. Patron çok hoş biri.

—— Avrupa'dan Mr.Angolon

Bu iyi bir üretici, iyi bir İngilizce iletişimci ve makinelerinizi beğendim Bu kaliteli ve güzel!

—— Afrika'dan Bay Mark

Güzel tedarikçi! Hızlı teslimatınızı ve hızlı üretim döngüsünü beğendim, sizinle irtibatta kalın

—— Amerika'dan Bay Jack

Ben sohbet şimdi

Building Material Steel Wall Panel Roll Forming Machine Hydraulic

Building Material Steel Wall Panel Roll Forming Machine Hydraulic
Building Material Steel Wall Panel Roll Forming Machine Hydraulic Building Material Steel Wall Panel Roll Forming Machine Hydraulic Building Material Steel Wall Panel Roll Forming Machine Hydraulic Building Material Steel Wall Panel Roll Forming Machine Hydraulic

Büyük resim :  Building Material Steel Wall Panel Roll Forming Machine Hydraulic

Ürün ayrıntıları:
Menşe yeri: CN
Marka adı: HC
Sertifika: ISO CE
Model numarası: HC-17
Ödeme & teslimat koşulları:
Min sipariş miktarı: 1 set
Fiyat: USD10000-16000 per set
Ambalaj bilgileri: Main machine is nude,the PLC is packed by carton box
Teslim süresi: 40 days
Ödeme koşulları: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Yetenek temini: 20 set per month

Building Material Steel Wall Panel Roll Forming Machine Hydraulic

Açıklama
Suitable market: Asia, European Usage: Wall panel
Capacity: 8-10m/min Roller station: 17 rows
Material: Steel plate, galvanized Worker: 1 only
Vurgulamak:

sheet metal rolling equipment

,

roof sheet making machine

Building Material Steel Wall Panel Roll Forming Machine Hydraulic



We take immense pride to introduce our company as one of the truthful manufacturers and exporters of Steel Wall Panel Roll Forming Machine. A wide gamut of these machines is Producing by us by implementing world class quality. we are offering you to this Steel Wall Panel Roll Forming Machine in as per your requirement. Our Steel Wall Panel Roll Forming Machine is widely appreciated by the customer all around the world due to smooth and constantaly performance. Further, this Steel Wall Panel Roll Forming Machine is Mostly used for manufacturing steel sheets that are used for the roofs and walls of buildings.



Building Material Steel Wall Panel Roll Forming Machine Hydraulic 0

Main parameters of Steel Wall Panel Roll Forming Machine

High Speed Blue Double Layer Roll Forming Machine For Roof Cladding
1 Suitable material Color steel sheet ,galvanized steel sheet, aluminium sheet
2 Width of material 1219mm or as you required
3 Thickness of material 0.3-0.6mm or as your needs
4 Working speed 10-20m/min
5 Main motor power 4kw with cycloidal reducer
6 Hydraulic station power 4kw
7 Electrical control system PLC control system
8 Shaft diameter 70mm
9 Roller station

17 rows

10 Material of roller High grade 45# forged steel plated with hard chrome plating
11 Material of cutting Cr12 mould steel with quenched treatment
12 Voltage 380V 3phase 50HZ or as the customer's requirements
13 Dimension 8200x1500x1510mm
14 Weight About 3.4 T
15 Working time Can be 24 hours
16 Workers 1-2 Only









































Please Note: All the parameters can be designed as your requirement.

Let me show you how to operate Steel Wall Panel Roll Forming Machine

Decoiling→Feeding & Guiding→Roll Forming→Cutting→Finished Products To Support Table

Building Material Steel Wall Panel Roll Forming Machine Hydraulic 1

Building Material Steel Wall Panel Roll Forming Machine Hydraulic 2



Why choose Huachen ?

We do high standard roll forming machine for export about 9 years

We have mature foreign trade team,senior engineers, experienced workers to make you satisfied.

We have machines at more than 80 countries and regions,and keep good business relationship.

we offer one year free warranty and free service for whole life of any machine.



Building Material Steel Wall Panel Roll Forming Machine Hydraulic 3

Building Material Steel Wall Panel Roll Forming Machine Hydraulic 4
