Galvanized Steel Ridge Cap Roll Forming Machine With 12 Rows rollers 45# steel

Galvanized Steel Ridge Cap Roll Forming Machine With 12 Rows rollers 45# steel
Galvanized Steel Ridge Cap Roll Forming Machine With 12 Rows rollers 45# steel Galvanized Steel Ridge Cap Roll Forming Machine With 12 Rows rollers 45# steel Galvanized Steel Ridge Cap Roll Forming Machine With 12 Rows rollers 45# steel Galvanized Steel Ridge Cap Roll Forming Machine With 12 Rows rollers 45# steel

Büyük resim :  Galvanized Steel Ridge Cap Roll Forming Machine With 12 Rows rollers 45# steel

Ürün ayrıntıları:
Place of Origin: Botou Hebei China
Marka adı: HC
Sertifika: ISO CE
Model Number: HC350
Ödeme & teslimat koşulları:
Minimum Order Quantity: 1set
Fiyat: 8000-29000USD
Packaging Details: Main machine is nude,the computer control box is packed by carton box
Delivery Time: 30days
Payment Terms: 30% deposit by T/T in advance and 70% balance after inspection confirmation before shipment
Supply Ability: 20 sets/month

Galvanized Steel Ridge Cap Roll Forming Machine With 12 Rows rollers 45# steel

Açıklama
Type: Ridge cap roll forming machine Usage: Roof ridge cap
Material: PPGI GI Capacity: 10-20m/min
Power: 4+4KW Control: PLC
Worker: 1 only Warranty: whole life
Vurgulamak:

metal forming machines

,

cold roll forming equipment

Galvanized Steel Ridge Cap Roll Forming Machine With 12 Rows

Galvanized Steel Ridge Cap Roll Forming Machine With 12 Rows rollers 45# steel 0

Galvanized Steel Ridge Cap Roll Forming Machine With 12 Rows rollers 45# steel 1

Our firm is engaged in offering a wide array of Galvanized Steel Ridge Cap Roll Forming Machine that is widely used in construction industry for making the roof tile and wall panel outside of building. The components used for its fabrication are procured from reliable sources of the market to deliver high performance and superior quality at users end. Our offered Galvanized Steel Ridge Cap Roll Forming Machine is highly appreciated for its outstanding functionality, sturdy construction, optimum strength, easy usage and longer functional life. We offer this machine in different specifications to fulfill the diverse needs of clients at most affordable prices.



Quick Detail:



1. Suitable to process: Color steel plate

2. Width of the plate: 370mm

3. Rollers: 12 rows

4. Dimensions: 6.2*1.15*1.51m

5. Power: 3+3kw

6. Rolling material: 45# steel(plated chrome on surface)

7. Thickness of the plate:0.3-0.6mm

8. Voltage: 380V 50Hz 3phases

9. Material of the cutting plate: Cr12

10. Hydraulic: 40#

11. Processing precision: Within 1.00mm

12. Control system: PLC control





Description:



Galvanized Steel Ridge Cap Roll Forming Machine Main parameter

No.

   Main parameter of Ridge Cap Roll Forming Machine

1

Suitable to process

Color steel plate

2

Width of the plate

370mm

3

Rollers

12rows

4

Dimensions

6200*1150*1510mm

5

Power

3+3kw

6

Rolling material

45# steel(plated chrome on surface)

6

Thickness of the plate

0.3-0.6mm

7

Productivity

4m/min

8

Diameter of the roller

Φ66 mm

9

Voltage

380V 50Hz 3phases

10

Material of the cutting plate

Cr12

11

Hydraulic

40#

12

Processing precision

Within 1.00mm

13

Control system

PLC control

Equipment components: Man-made uncoiler-roll forming machine-computer control system-hydraulic control system-press form-cutting





Application



This product is widely used in many kinds of industrial factory, civilian buildings, and Roof board for attached part product. It has advantage of pretty appearance, durable using and so on.

Galvanized Steel Ridge Cap Roll Forming Machine With 12 Rows rollers 45# steel 2Galvanized Steel Ridge Cap Roll Forming Machine With 12 Rows rollers 45# steel 3Galvanized Steel Ridge Cap Roll Forming Machine With 12 Rows rollers 45# steel 4



Competitive Advantage



 1. sample customized

2. short production cycle

3. quality guarantee

4. high-effect, low consume

5. provide lifelong technical support

Galvanized Steel Ridge Cap Roll Forming Machine With 12 Rows rollers 45# steel 5
