Customized Batten Profile GI Drywall Roll Forming Machine with 45m/min Speed and Cr12 Rollers

Customized Batten Profile GI Drywall Roll Forming Machine with 45m/min Speed and Cr12 Rollers
Customized Batten Profile GI Drywall Roll Forming Machine with 45m/min Speed and Cr12 Rollers
Customized Batten Profile GI Drywall Roll Forming Machine with 45m/min Speed and Cr12 Rollers Customized Batten Profile GI Drywall Roll Forming Machine with 45m/min Speed and Cr12 Rollers Customized Batten Profile GI Drywall Roll Forming Machine with 45m/min Speed and Cr12 Rollers Customized Batten Profile GI Drywall Roll Forming Machine with 45m/min Speed and Cr12 Rollers Customized Batten Profile GI Drywall Roll Forming Machine with 45m/min Speed and Cr12 Rollers Customized Batten Profile GI Drywall Roll Forming Machine with 45m/min Speed and Cr12 Rollers

Büyük resim :  Customized Batten Profile GI Drywall Roll Forming Machine with 45m/min Speed and Cr12 Rollers

Ürün ayrıntıları:
Menşe yeri: Çin anakarası
Marka adı: HC
Sertifika: CE
Model numarası: HC27X31
Ödeme & teslimat koşulları:
Min sipariş miktarı: 1set
Ambalaj bilgileri: Ana makine çıplaktır, kontrol kabini karton kutu ile paketlenmiştir.
Teslim süresi: 30 gün
Ödeme koşulları: T/T, L/C
Yetenek temini: 20 set/ay
İletişim

Customized Batten Profile GI Drywall Roll Forming Machine with 45m/min Speed and Cr12 Rollers

Açıklama
Uygun malzeme: GI PPGI Kapasite: 45m/dak
Ağırlık: 2.5t Silindir malzemesi: CR12
Başvuru: Alçıpan Sistemi Garanti: 1 yıl
Vurgulamak:

45m/min Drywall Roll Forming Machine

,

Cr12 Rollers Batten Profile Roll Forming Machine

,

Drywall System GI Roll Forming Machine

Customized Batten Profile GI Drywall System Roll Forming Machine
Product Description

Our Batten Profile GI Roll Forming Machine can produce various steel roof and wall panels, a new building material widely used for factories, warehouses, garages, gymnasiums, exhibition centers, cinemas, and theaters. Key advantages include easy installation, short construction period, aesthetic appeal, light weight, and high strength.

Technical Specifications
Main Roll Forming Machine
Roller station 12 rows
Material of roller Cr12
Material of cutter Cr12 mould steel with quenched treatment
Material Specifications
Material PPGI, GI, AL
Material width Customized
Material thickness 0.4-0.5mm
Performance Parameters
Speed 45m/min
PLC system DELTA
Weight 2.5T

With 20 years of experience in manufacturing high-standard roll forming machines for export, we offer:

  • Mature foreign trade team, senior engineers, and experienced workers
  • Machines installed in over 130 countries and regions
  • One year free warranty and lifetime free service for all machines
Certifications
Customized Batten Profile GI Drywall Roll Forming Machine with 45m/min Speed and Cr12 Rollers 0
Customized Batten Profile GI Drywall Roll Forming Machine with 45m/min Speed and Cr12 Rollers 1
Customized Batten Profile GI Drywall Roll Forming Machine with 45m/min Speed and Cr12 Rollers 2
Machine Components
Customized Batten Profile GI Drywall Roll Forming Machine with 45m/min Speed and Cr12 Rollers 3

Rollers: Welded steel frame structure with AC frequency conversion motor reducer drive. Features include chain transmission, roller surface polishing, hard plating, heat treatment, and chrome coating (0.05mm thickness). Roller material: Forging Steel 45# with heat treatment.

Main Roll Former
Customized Batten Profile GI Drywall Roll Forming Machine with 45m/min Speed and Cr12 Rollers 4

Custom-designed rollers based on profile drawings, featuring welded steel frame structure, AC frequency conversion motor reducer drive, and chain transmission for durable performance and high-quality finished products.

Customized Batten Profile GI Drywall Roll Forming Machine with 45m/min Speed and Cr12 Rollers 5
Hydraulic Cutting System

Hydraulic-driven system with automatic positioning for precise dimension cutting. Features non-stop cutting capability with Cr12 blades that undergo quenching treatment.

Our Services
Customized Batten Profile GI Drywall Roll Forming Machine with 45m/min Speed and Cr12 Rollers 6
Pre-Sales Service
  • Inquiry and consulting support
  • Sample testing support
  • Factory viewing arrangements
Customized Batten Profile GI Drywall Roll Forming Machine with 45m/min Speed and Cr12 Rollers 7
After-Sales Service
  • Machine installation and operation training
  • Overseas engineer support for machinery service
Packing & Delivery
Customized Batten Profile GI Drywall Roll Forming Machine with 45m/min Speed and Cr12 Rollers 8

Dimensions: 5600 (L) × 850 (W) × 1510 (H) mm
Weight: 2.5T

  • Main Roll Forming Machine and un-coiler: nude packing (water-proof plastic available upon request)
  • PLC control system and motor pump: packed with water-proof paper
  • Spare parts: packed in carton boxes
  • Shipping: One 40' container required per machine set
Customized Batten Profile GI Drywall Roll Forming Machine with 45m/min Speed and Cr12 Rollers 9
Customized Batten Profile GI Drywall Roll Forming Machine with 45m/min Speed and Cr12 Rollers 10
Customized Batten Profile GI Drywall Roll Forming Machine with 45m/min Speed and Cr12 Rollers 11
